ElectraGlide (Series 4)
The ElectraGlide rear-wheel-drive powered wheelchair is constructed with lightweight aluminium, making it easy to carry and store. The unique folding mechanism allows the chair to fit in the luggage compartment of a car. The strong aluminium frame reduces weight, which increases the endurance and range of the battery.
Gallery
Description
Overview
The ElectraGlide rear-wheel-drive powered wheelchair is constructed with lightweight aluminium, making it easy to carry and store. The unique folding mechanism allows the chair to fit in the luggage compartment of a car. The strong aluminium frame reduces weight, which increases the endurance and range of the battery.
Features
Specifications
Max Recommended User Weight
150Kg – AS3695
Chair weight
49 – 52kg
Rear Wheels
12-1/2 x 2-1/4" (Pneumatic)
Front Castors
200×50 (Pneumatic)
Drive Wheels
Rear
Overall Length
95cm
Overall Width
43cm chair width = 60cm overall width
Seat Frame
Aluminium folding modular frame
Seat Width
37 – 52cm
Seat Depth
33, 37, 40, 43, 46, 49, 52, 55cm
Seat Height
51cm Std – 46cm with low seat height kit
Back Height
To client requirements, in 3cm graduations
Seat Upholstery
Sailcloth material with seat adjustment
Arm Rests
Full Length, Non Adjustable
Leg Rests
Detachable swing aways, plastic footplates
Frame Colour
Choose from Glide colour range
Brakes
Electromagnetic and manual attendant
Controls
PG Rnet
Battery
2 x 12V 24Amp Hour Batteries
Charger
24V 8 Amp
Range
18 Km
